The Eicher Skyline 2090 L AC school bus epitomises safety, comfort, and performance within its spacious 2350 mm wide bus body. Loaded with advanced safety features such as silent and grease-free parabolic suspension, and radial tubeless tires, it ensures maximum safety and security. Powered by the cutting-edge BSVI E474 engine, this bus guarantees robust performance. Its excellent fuel efficiency and minimal maintenance costs significantly enhance your profitability.
| SPECIFICATIONS | 2090 L AC |
|---|---|
| Seating Capacity | 51+1+D (3X2), 35+1+D(AC) PB 2X2 |
| Wheelbase | 5240 mm |
| Overall Length | 9584 mm |
| Overall Width | 2350 mm |
| Overall Height | 3070 mm |
| Min Ground Clearance | 187 mm |
| Front Overhang | 1200 |
| Rear Overhang | 3144 mm |
| Turning Circle Diameter | 19.4 m |
| Engine Make | E474 |
| Displacement (cc) | 2960 |
| Power | 105kW @ 3200 Rpm |
| Torque | 400Nm @ 1200- 2500 Rpm |
| Clutch | 310 mm |
| Transmission Make | ET35S6 |
| Transmission Type | synchromesh (6 Speed,1 Rev) |
| GVW | 9.9 t |
| Chassis Type | Domex 650 |
| Chassis C frame dimensions | 200x65x5 mm |
| Fuel Tank Capacity | 160 litres |
| Brakes | Dual Circuit 'S' Cam Full Air brakes |
| Tyres | 235/75 R17.5- 14PR (Radial Tubeless ) |
| Suspension Front | Parabolic with Anti-Roll Bar |
| Suspension Rear | Parabolic |
| Steering | Power Steering |
| Battery | 12V 130Ah |
| Alternator | 110A x 2 |
| Flooring | Vinyl |
| DEF Tank Capacity | 19 litres |
